Three-Layer Pharmaceutical Tablet Press

The Three-Layer Tablet Press Machine is a high-precision and efficient equipment specially designed for manufacturing three-layer tablets. It is widely used in pharmaceutical, chemical, food, and related industries to compress granular materials into multi-layer tablets with high efficiency and uniformity.

29 stations
max.24mm oblong tablet
up to 52,200 tablets per hour for 3 layer

Pharmaceutical production machine capable of single layer,double-layer and three layer tablets.

Send email to us

Product Detail

Product Tags

Features

1. Structural Features

This tablet press is mainly composed of a frame, a powder feeding system, a compression system, and a control system. The frame is made of high-strength materials, ensuring stable operation and long service life. The powder feeding system can accurately feed different materials for each layer, ensuring the uniformity of the tablet layers.

2. Working Principle

During operation, the lower punch descends to a certain position in the die hole. The first powder is fed into the die hole to form the first layer. Then the lower punch rises slightly, and the second powder is fed to create the second layer. Finally, the third powder is added to form the third layer. After that, the upper and lower punches move towards each other under the action of the compression system to compress the powders into a complete three-layer tablet.

Advantages

• Three-layer compression capability: Allows for the production of tablets with three distinct layers, enabling controlled release, taste masking, or multi-drug formulations.

• High efficiency: Rotary design ensures continuous and fast production with consistent tablet quality.

• Automatic layer feeding: Ensures accurate layer separation and uniform material distribution.

• Safety and compliance: Designed in accordance with GMP standards with features like overload protection, dust-tight enclosures, and easy cleaning.

• High precision: It can easy control the thickness and weight of each layer, ensuring the quality and consistency of the tablets.

• Flexibility: It can be adjusted to produce tablets of different sizes and shapes, meeting various pharmaceutical and industrial needs.

• Efficient production: With a reasonable design and advanced control system, it can achieve high-speed production, improving production efficiency.

• Safety and reliability: Equipped with multiple safety protection devices to ensure the safety of operators and the stable operation of the equipment.

This three-layer tablet press plays an important role in the pharmaceutical, food, and other industries, providing reliable technical support for the production of high-quality three-layer tablets.

Specifications

Model		TSD-29T
Number of punches		29
Max.pressure kn		80
Max.tablet diameter mm		20 for round tablet 24 for shaped tablet
Max.filling depth mm		15
Max.tablet thickness mm		6
Turret speed rpm		30
Capacity pcs/h	1 layer	156600
	2 layer	52200
	3 layer	52200
Main motor power kw		5.5
Machine dimension mm		980x1240x1690
Net weight kg		1800
