Compressed Biscuit Hydraulic Press Machine

The Compressed Biscuit Hydraulic Press Machine is a specialized equipment designed for forming high-density compressed biscuits, emergency rations or energy bars.

Utilizing advanced hydraulic technology ensures a large and stable pressure, uniform density and precise shaping. It is widely used in the food industry, military rations, survival food production, and other applications requiring compact and durable biscuit products.

4 stations
250kn pressure
up to 7680 pcs per hour

Large-pressure production machine capable of food industry compressed biscuits.

Send email to us

Product Detail

Product Tags

Specification

Model	TBC
Max. Pressure (kn)	180-250
Max. Diameter of product(mm)	40*80
Max.filling depth (mm)	20-40
Max.thickness of product(mm)	10-30
Max.working diameter(mm)	960
Turret speed (rpm)	3-8
Capacity (pcs/h)	2880-7680
Main motor power (kw)	11
Machine dimension (mm)	190012601960
Net weight (kg)	3200

Features

• Hydraulic System: The machine is powered by a servo drive system and utilizes hydraulic pressing for operation which is stable and adjustable pressure output.

• Precision Molding: Ensures uniform biscuit size, weight, and density.

• High Efficiency: Supports continuous operation to meet mass production needs.

• User-Friendly Operation: Simple interface and easy-to-maintain structure.

• Especially for rotary type press machine and difficult- to-form material, the pressure-forming process is not easy to rebound by pressing the hydraulic pressure and holding function, and is suitable for larger product sizes.

• Versatility: Suitable for various compressed food materials, including biscuits, nutrition bars, and emergency food.
